GFRG deepen the design steps

2021 10/24

GFRG Deepen the design steps:
1. familiar with the construction drawings (to understand the technical parameters and requirements)
2. Mark the GFRG product section on the drawing
3. Classification / partitioning GFRC
4. The local GFRC products for force analysis, which determines the product installation
5. Draw GFRC product installation diagram --- CSD
6. The drawings will be reviewed and made amendments
7. Submit a formal CSD drawing ----- (used to indicate the product installation method)
8. Confirm that after drawing PSD (production drawings --- for the workshop single product schematic)
9. Design Director Review Signature

10. Drawing distribution --- text control department (for sealing)
